Inverter Single-phase continuous / Alternating current

Educational objectives
• Studying of a 24V single-phase inverter, in half bridge and in bridge

Selected reference CO-1020
Quantity

Selected reference CO-1020
Selected reference CO-1020

PANEL: A "Single-phase, static, half-bridge voltage converter (2 switches)"
The diode and power transistor operate by cross-barring
Presentation of symmetrical control
Presentation of the Pulse-Width Modulation control: Bipolar PWM wave
Experiment N°1:    Throughput over resistive load (R)
Experiment N°2:    Throughput over inductive load (R, L)
Experiment N°3:    Throughput over resonant load (R, L, C)

PANEL B "Single-phase, static, bridge voltage converter (4 switches)"
Presentation of offset control
Presentation of the Pulse-Width Modulation control: Three-pole PWM wave
Experiment N°1:    Throughput over resistive load (R)
Experiment N°2:    Throughput over inductive load (R, L)
Experiment N°3:    Throughput over resonant load (R, L, C)
        Application to induction heating
Experiment N°4:    Application to speed variations in an alternating
        current motor
Experiment N°5:    Application to a backup power supply
Using the CO-1000 test bench as a charger.
